Find 3 Inch to 5 Inch Lift Kits for your Tahoe
BDS 4-Inch Suspension Lift Kit with Rear Coil Springs with NX2 Nitro Shocks (15-19 4WD Tahoe w/ Stock Cast Aluminum or Stamped Steel Control Arms & w/o AutoRide or MagneRide)Find parts that fit my vehicle
Item CT36815
$0.00
2 Reviews
Our Price
$2,224.65 kit
Ship to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
Will this fit your Vehicle?
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- BDS Suspension Lift Kit
- Includes Rear Coil Springs with NX2 Nitro Shocks
- Lift of 4 Inches
- Matte Black and Polished Chrome Finish
- Improved Performance and Handling
- Bolt-On
- Direct Replacement
- Comes in Kits
- Fits 2015-2019 4WD Chevrolet Tahoe with Stock Cast Aluminum or Stamped Steel Control Arms and without AutoRide or MagneRide Models
| Brand | BDS |
| Lift Height | 4.00 Inch |
| Lift Kit Type | Spacer Lift |
| Lift Kit Max Tire Size | 33 Inch |
| Lift Kit Includes Shocks | Shocks Included |
Description
Suspension Performance Upgrade. The BDS Suspension Lift Kit delivers enhanced off-road performance and a commanding stance for 2015-2019 4WD Chevrolet Tahoe models equipped with stock cast aluminum or stamped steel control arms and without AutoRide or MagneRide systems. With a 4-inch lift height, this kit improves ground clearance, handling, and overall ride quality, making it ideal for drivers seeking both aesthetic appeal and off-road capability.
Construction and Appearance. Featuring a combination of matte black and polished chrome finishes, this kit includes premium components such as rear coil springs with NX2 Nitro shocks, steering knuckles, crossmembers, differential drop brackets, and CV spacers. All components are built for durability and resistance to harsh driving conditions, while the bolt-on design ensures a seamless fit and reliable performance. The extensive hardware set guarantees long-lasting strength and secure installation.
Installation. Designed for adaptable installation as a direct replacement, this lift kit bolts onto factory mounting points, minimizing the need for modifications. The comprehensive kit includes all necessary hardware, spacers, brackets, and skid plates for a complete suspension transformation. Professional installation is recommended to ensure proper alignment and optimal performance after installation.
Application. This BDS Suspension Lift Kit fits 2015-2019 4WD Chevrolet Tahoe models with stock cast aluminum or stamped steel control arms and without AutoRide or MagneRide systems. Engineered to enhance off-road capability and provide a more aggressive stance, it offers a balanced combination of style, performance, and durability for adventurous drivers.
BDS BDS734H
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (2) Rear Coil Spacers
- (1) Rear Track Bar Bracket
- (1) Track Bar Spacer
- (2) Bump Stops
- (1) Rear Track Bar Support Bracket
- (2) Sway Bar Links
- (4) Hourglass Bushings
- (1) 0.875 x 0.134 x 1.670 Sleeve
- (1) 0.750 x 0.109 x 2.985 Sleeve
- (4) 0.625 x 0.060 x 1.475 Sleeves
- (4) 0.750 x .095 x 1.98 Sleeves
- (4) 7/16"-14 x 1" Grade 5 Bolts
- (4) 7/16"-14 Prevailing Torque Nuts
- (8) 7/16" SAE Flat Washers
- (2) 12mm-1.75 x 70mm Class 10.9 Bolts
- (2) 12mm-1.75 Prevailing Torque Nuts
- (4) 7/16" USS Flat Washers
- (1) 8mm-1.25 x 100mm Class 8.8 Bolt
- (1) 5/16" SAE Thru-Hardened Flat Washer
- (1) Cable Clamp
- (4) 3/8"-16 x 1-1/4" Bolts
- (4) 3/8"-16 Prevailing Torque Nuts
- (8) 3/8" SAE Thru Hardened Washers
- (2) Wire Clips (Fastenal #0708762)
- (2) 12 x 3/4" Self-Drilling Hex Head Screws
- (1) 1/2"-13 x 1-1/2" Grade 8 Bolt
- (1) 1/2"-13 Prevailing Torque Nut
- (2) 1/2" SAE Flat Washers
- (1) 9/16"-12 x 3-1/2" Grade 8 Bolt
- (1) 9/16"-12 Prevailing Torque Nut
- (2) 9/16" SAE Flat Washers
- (4) Steering Knuckles
- (2) Lower Ball Joint Spacers
- (2) Tie Rod Ends
- (2) Tie Rod End Nuts
- (2) Crossmembers
- (2) Differential Drop Brackets
- (2) CV Spacers
- (4) Sway Bar Drops
- (2) Sway Bar Link Sleeves
- (8) Sway Bar Link Bushings
- (8) Sway Bar Link Washers
- (2) 3/8” x 9” Bolts
- (2) 3/8” Nylock Nuts
- (2) 5/8”-11 x 4-1/2” Bolts
- (2) 5/8”-11 x 5-1/2” Bolts
- (4) 5/8”-11 Lock Nuts
- (8) 5/8” SAE Washers
- (12) 10mm-1.5 x 65mm SHCS
- (2) 1/2” x 1-3/4” Bolts
- (2) 1/2”-13 Lock Nuts
- (4) 1/2” SAE Washers
- (1) 5/8” x 1-3/4” Bolt
- (1) 5/8” SAE Thru Hardened Washer
- (1) 5/8” SAE Washer
- (1) 5/8”-11 Lock Nut
- (2) 9/16”-12 x 4” Bolts
- (4) 9/16” SAE Flat Washers
- (2) 9/16”-12 Lock Nuts
- (4) 10mm-1.50 x 40mm Bolts
- (4) 10mm Washers
- (1) Front Skid Plate
- (2) Skid Plates
- (1) Weld-In Plate
- (2) Brake Line Brackets
- (7) Cable Ties
- (1) Thread Locker
- (4) Wire Clips
- (2) 1/4"x3/4” Self-Tapping Bolts
- (8) 1/2” x 1-1/4” Bolts
- (8) 1/2” SAE Washers
- (4) 10mm-1.50 x 120mm Socket Head Cap Screws
- (4) 10mm Flat Washers
