Installation Time
(approx) 6 Hours
Difficulty Level:
Mechanical expertise or professional installation required.
Installation Guides
No guide available for this part yet.
FREE 1 to 3-Day Delivery on Orders $149+ Details
On3 Performance Single Turbo System with 7875 Cast Wheel Journal Bearing Turbo (14-18 5.3L Silverado 1500)Find parts that fit my vehicle
Item S220745-C
Our Price
$2,899.00 - $3,348.00
Military, Medical & First Responders
$149.40 Available in AT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features
- Bolt-On Upgrade Producing Over 200 Rear Wheel Horsepower
- Compatible With Street Driving, Drag Racing, And Towing Applications
- Driver Side Factory Manifold With Tubular Upgrades Available
- Custom Fabricated Cast Stainless Steel Turbo Manifold Designed To Clear 4x4 Transfer Case And Driveshaft
- Gen 2 Cast Stainless Steel Header Standard
- Standard 70mm Journal Bearing Turbocharger Included; Optional Larger Billet Wheel Turbo Upgrades Available
- Completely Divided Bank-To-Bank Exhaust Design For Accurate Tuning
- On3 44mm V-Banded Wastegate Positioned At T4 Flange For Boost Control
- 304 Stainless Steel Stepped Downpipe From 3.0" To 3.5" With Thick 16-Gauge Wall Tubing
- Cold Side Uses 3.0" 304 Aluminum Tubing With Bead Rolled Couplers And Stainless T-Bolt Clamps
- Custom Air-To-Air Intercooler Core Available In Standard 3.5" Or Larger Race Core Variants (Race Core May Require Additional Trim)
- Optional Turbo Oil Drain System With Electric Pump Available To Avoid Drilling Oil Pan
- Factory Mass Air Flow Meter Compatible Up To 12-15psi Boost
- Stock Fuel Pump Can Support Up To 550rwhp On Pump Fuel; Fuel Upgrades Needed For E85 Or Higher Power
- Designed For Versatile Use Including Street Driving, Drag Racing, And Towing With Responsive Boost
- Step-By-Step Bolt-On Installation Designed For Weekend Completion By Moderate Mechanical Experience; Some Configurations May Require Minor Modifications
- Includes Adapter To Tie Into Factory Exhaust Connection
- Fits 14-18 5.3L Silverado 1500
Description
Performance Enhancement. The On3 Performance Single Turbo System with a standard 70mm journal bearing turbocharger is engineered to significantly increase power output and torque of the 5.3L Silverado and Sierra 1500. This bolt-on turbocharger system is an accessible upgrade that improves throttle response and delivers on-demand power, enhancing towing capability and driving enjoyment.
Construction and Appearance. Featuring a durable Gen 2 cast stainless steel turbo manifold with a custom fabricated design, the system uses thick 16-gauge 304 stainless steel tubing for the downpipe and lightweight 304 aluminum tubing for the cold side. Components are finished to withstand intense heat cycles and daily use while maintaining a clean and professional engine bay appearance.
Installation. Installation is designed to be straightforward and feasible over a weekend for individuals with moderate mechanical experience. An optional electric oil drain pump system is available to avoid drilling the oil pan, but this is not included as standard. The system employs a simple bolt-on setup that integrates with factory exhaust connections.
Application. This single turbo system fits 14-18 5.3L Silverado 1500 models and is engineered specifically to accommodate the truck’s 4x4 transfer case and driveshaft configuration without modifications.
On3 Performance 1417-1515
1417-1514
1417-1513
1417-1512
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) 78/75 Cast Wheel Journal Bearing Turbocharger
- (1) Set Of Mandrel Bent Hot Side Piping
- (1) Set Of Cold Side Intercooler Piping
- (1) Front Mount Intercooler
- (1) Turbo Manifold And Crossover
- (1) Wastegate
- (1) Blow Off Valve
- (1) Oil Feed And Return Line Kit
- (1) Full Mounting Hardware Kit
- (1) Installation Instructions
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My Silverado 1500
- 5.3L V8 - 14, 15, 16, 17, 18
