Installation Time
(approx) 1 Hour
Difficulty Level:
Simple installation for anyone.
FREE 1 to 3-Day Delivery on Orders $149+ Details
Bilstein B8 5160 Series Front Shock 4 to 6-Inch Lift
(99-04 4WD F-250 Super Duty
Item SD55334
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- Part Number 25-311877
- Product Type Suspension Shock Absorber
- Series B8 5160
- Weight Lbs 7.68
- Collapsed Length In 15.96
- Extended Length In 27.13
- Collapsed Length Mm 405.5
- Extended Length Mm 689.2
- Stroke Travel Length In 11.06
- Lower Mount Type Eye 12mm
- Upper Mount Type Eye 16mm
- Internal Design Monotube
- Finish Zinc Plated
- Reservoir Yes
- Body Design Smooth Body Non-Coilover
- Body Diameter Od 2.0 In
- Piston Diameter 46mm
- Boot Included No
- Spring Seat Included No
- Billet Reservoir Clamp Included Yes
- Shaft Diameter 14mm
- Adjustable Damping Non-Adjustable
- Country Of Origin Us
- Quantity Per Vehicle 2
- Warranty Limited 2-Year Warranty
- Fits 99-04 4WD F-250 Super Duty
| Brand | Bilstein |
| Shock Type | Non-Adjustable |
| Shock Lift Height | 4 to 6-Inch Lift |
Description
High-Performance Suspension. The Bilstein B8 5160 Series Front Shock 4 to 6-Inch Lift is engineered to enhance suspension performance for lifted trucks. It improves wheel travel and ride quality, ensuring better control and durability on challenging terrains. Its specialized design targets off-road enthusiasts seeking increased cooling and consistent shock absorption.
Construction and Appearance. This shock absorber features a monotube internal design with a zinc-plated finish for corrosion resistance. The smooth body construction includes a 2.0-inch diameter tube and a 46mm piston for reliable damping performance. It is equipped with a billet reservoir clamp and a 360-degree swivel banjo hose fitting for a clean, functional, and low-profile installation.
Installation. Installation is straightforward, designed as a direct fit with no drilling required. It mounts easily using the supplied eyelet mounts sized 12mm for the lower and 16mm for the upper connection points.
Warranty. This shock absorber includes a limited 2-year warranty.
Application. Designed specifically for the 1999 to 2004 Ford F-250 Super Duty 4WD models with 4 to 6-inch suspension lifts.
Bilstein 25-311877
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Install Details & What's in the Box
Installation Info
What's in the Box
- (1) Front Shock Absorber
4.9
Reviews of Bilstein Suspension Products (500+)
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My F-250
- 4.6L V8 - 99
- 5.4L V8 - 99, 00, 01, 02, 03, 04
- 6.0L V8 Power-Stroke - 03, 04
- 6.8L V10 - 99, 00, 01, 02, 03, 04
- 7.3L V8 Power-Stroke - 99, 00, 01, 02, 03
