(approx) 2 Hours
Light to Moderate mechanical skill required.
$809.99 (each)FREE Shipping
Hey guys, it's Joe from American Trucks, and today, we're gonna be taking a closer look at the Barricade HD off-road front bumper with LED lighting, fitting all 09 to 14 F-150s, excluding the Raptor models. Now, there's gonna be a great option for you if you're looking for a relatively budget-friendly off-road-capable front bumper that throws in some extra auxiliary lighting.So what do we have going on here with the HD off-road? First, let's talk about build quality. And, as you'd expect, this thing is made out of heavy-duty steel, 5/32 inch, it's sealed in that ultra-durable two-stage black powder coating, which is not just there to add to the looks, albeit it does match a blackout look almost perfectly. And our matte black grille here is pretty much a perfect match but it also serves as a nice layer of protection over top of that steel, against the elements.This bumper was also designed with off-roading in mind, we're gonna get this side by side next to the factory front bumper in just a second to really highlight this, but suffice to say, the HD off-road bumper really tapers up at the corners here, and that is designed to help you out with approach angle and that's going to improve your overall off-road experience. In order for you to go over something, you need to get your tire up onto it, and approach angle is the first step.Now, as you could've probably told from the title, this bumper also includes some auxiliary LED lighting, 2 5-watt Cree LED light cubes, they're 3 inches in size. They're IP67-waterproof, which means they can withstand up to a meter of water for 30 minutes. Aluminum housing, polycarbonate lens, and the light output is going to come at a color temperature of around 6,000 K. That's gonna be a very bright white leaning very slightly toward the blue side. They're also completely plug and play. And if your truck doesn't come with fog lights from the factory, Barricade even throws in a wiring harness for you to hook up to the battery.This bumper also gives you the option to add even more LED lighting, if that's your thing. You can fit a 20-inch light bar in this slot in the center here, and if you remove these two side grates, you can do up to a 30-inch up top. You can even mount one up here, that will take up to a 30-inch light bar. And all the brackets you need to mount those up are included in the kit.This bumper also retains some very important features from the factory front bumper. It does have cutouts along the bottom right here. So, if your truck has tow hooks, they'll be able to mate up seamlessly with this barricade front bumper and you get to keep those as a recovery point. That's a really nice touch. And on top of that, the kit even includes a front license-plate mounting bracket. If you live in a state that requires a front plate, you'll be good to go right out of the box with this thing.Some other options for you to trick this thing out would include an Overrider Hoop, and that would go over a light bar if you do decide to put one up here. There's also a skid plate that is designed for this bumper specifically. However, both of those things are not included in the kit and are an optional extra. Same thing goes with the matching rear bumper, Barricade does make one, however, again, it won't come with this bumper obviously, an optional extra to really tie together the look of your F-150.Pricing for the HD off-road, let's talk about that a little bit. And simply put, it's gonna drop in right around that $800 range. And for what you're getting here, that is a really good return on investment. Basically, some of the most budget-friendly bumpers we offer on the site started around 600. And for some of the big name brands that include LED lighting like this one, you can expect to pay around $1,500 to $2,000. So at 800 bucks, this is a deal. There are a lot of optional extras out there for it as well and the extra LED lighting is really a nice touch.So next, let's get to the good stuff. How are you gonna get this thing installed on your F-150? Well, first things first, it's pretty easy. Again, the lights are plug-and-play, harness is included, and that does have a switch on it. There are no modifications required to install this onto your F-150. It is pretty heavy though. And for that, I'm gonna give it an easy two out of three wrenches on our difficulty meter. At most, this should take you about an hour or 2 in the driveway with nothing but some basic hand tools. So, without any further ado, let me show you what tools you'll need and how it's done.Tools we use for this install are going to include an impact, extension, ratchet, socket set ranging from 21 millimeters all the way down to 8 millimeters. A wrench set ranging from 18 millimeters all the way down 10 millimeters. And these two Allen keys which do come included in the kit.Now, before we go and loosen up any of the hardware holding on our front bumper, we're going to have to crawl under our F-150 and unplug the fog lights. And in order to unplug those, we're just gonna pull back on this release tab and push down at the same time. We're gonna do the same thing over here on the other side as well.Now we're gonna loosen up these 21-millimeter nuts holding our bumper to the frame rail. Now, one thing to note, this might be blocked with an air-dam piece. If that's the case, you could use a trim-panel removal tool to give that out of the way. And after that's done, we can come in here with the 21-millimeter socket on the impact to loosen up those nuts.That's one done. There's another one on the opposite side of the frame rail as well. And then, we could come over and do the same thing on the opposite side as well. One thing to note is these two nuts are the last thing holding the bumper to the truck. So, once you get them removed, be careful, have [inaudible 00:05:50] the bumper to hold it still, and then, you could take this off.So, now that we have our factory front bumper off of our F-150, we're gonna do a little bit of work and build up our Barricade here, and then, we're gonna put the two next to each other and point out some differences between these two bumpers.Now, there's a lot of stuff on the table, I'm gonna tell you exactly what each one of these things is for. And then, we're gonna go ahead and apply them to our barricade. So, starting over here, this big plate...this is gonna go right here in the middle of this slot. This is where a 20-inch light bar would go, if you had one of those. It doesn't come included in the kit, but if you did have one, it would fall in right there. These square grates are gonna go on the side of that. This is gonna be the spot for a 30-inch light bar, if you had one of those, this could also go in the center slot right here. Or you could use these brackets over here to run that up top, and then, these brackets right here, they would go in this slot in the center. This bracket right here, this is for a front plate, if your state does require those, you do have that bracket available for you. And then, over here are light cubes, they're gonna go on the outsides here. And if you didn't wanna run those, you have two grates to fill in those slots as well.So, we're gonna start off with this big center plate right here. And that is gonna drop in right in the center and it's going to secure with some button head screws and 10-millimeter nuts. Now, one thing about these...that I like to do at least is I like to make sure that the button head of the bolt is behind the grille. That way, if you do ever see through that for any reason, you won't see the nut and the threaded portion. Just a little bit nicer to do it this way but it's really up to you. And to tighten those down, we're just gonna use the Allen key that comes in the kit, as well as a 10-millimeter wrench. And we're gonna do the same thing for these smaller square grates on the outside as well.Now, before we drop our fog lights in, we are going to have to install the bracket for them. And in order to do that, we're just gonna slide that in between the fins like so. This does have a notch cut out of that, you wanna make sure that that is facing forward so that you get the most amount of movement possible out of this if you do need to adjust the fog light.Now, once we have that bracket installed, what we're going to do is drop a nut sort of down the bracket. And the fin has a cutout in it to hold the nut still while we come in from the side with the bolt. And with that started, we're just gonna use the Allen key that comes with the lights to tighten it down. We're gonna do the same thing over on this side as well. And we're gonna do the same exact thing for the other fog light, and then, we can install this to our bumper.So now, to install this what we're gonna do is take that bracket we just hooked up to our light, we're gonna feed a 13-millimeter bolt through there. And you can see, this bracket has those two notches cut out of it, and that's to hold the bolt head still while we come through into our bumper. And then, we can thread on the lock washer and 13-millimeter nut. And again, we're just gonna do the same thing for the other side over here. And if you buy this bumper without these fog lights, again, which you can, you would just be installing those filler plates instead.So our Barricade bumper is just about ready to go onto our F-150. But before we do, I'd figure now would be the perfect time to sit it down on the ground next to our old factory front bumper and point out some key differences. Now, the first and most obvious, it's gonna come in the looks department. We're ditching this factory body color here with all of this plastic along the bottom for some real heavy-duty steel. 5/32-inch steel plate, this is going to be a hell of a lot stronger than this factory stuff over here, especially that plastic along the bottom.Now, this Barricade bumper wasn't designed with just looks in mind but also off-roading in mind as well. You can really tell, when you get to the ends of this factory front bumper, you got that square edge to it. That is really gonna hurt your approach angle. This Barricade takes advantage of that by tapering up on the sides, and that is just going to improve your overall off-roading experience which is gonna be a huge plus for the HD off-road.The next upgraded area is gonna be the fog lights. We're ditching this factory stuff here, standard halogen bulb with that reflector housing for some more modern LEDs. That's really gonna clean up that color temperature, we're ditching the yellow for a little bit of cool white leaning very very slightly toward the blue side. That's gonna be a huge upgrade in the looks department but also light throne, [SP] as this is a little bit old-school, that's a little bit more modern, like I said earlier.With the Barricade, you also get the ability to add some light bars which you wouldn't be able to on this factory front bumper. Again, you could do a 30-inch up top, a 20-inch, or a 30-inch in that slot in the middle, if you'd like.Now, what really sets the Barricade over the top it's the factory features that you're keeping. Again, you do have a front-plate mount, over here on a Barricade, if you need it. And your tow hooks, they're gonna work just fine with either of these two bumpers. So, we do have a little bit of prep work to do on our truck before we drop our Barricade bumper in place. We have to install some mounting brackets, we're gonna grab those and they're gonna bolt right up to our frame rail.So, we can go ahead and grab the right mounting bracket. You can see, this one is on the driver side and it has that small D marked into it right there. And that is just going to install, pretty obviously, like so. Now, once we have that in place, we're gonna take the 18-millimeter hardware included in the kit and bolt that down. And, on the opposite side, we're installing a flat washer, lock washer, and another 18-millimeter nut.And over here, on the opposite side of the frame rail, we're gonna do the same exact thing. Now, as you can tell, this bracket is slotted so you get a little left and right on the bracket. And then, the frame rail is slotted for your up and down. For right now, we're gonna aim for the middle. But if you do need some adjustment, you could always loosen these up later on and tighten it back down. And again, 18 millimeters on both sides. And we're going to do the same thing over on the other frame rail as well.So, now we can go ahead and put our bumper up. And that is gonna rest on top of our mounting brackets. And now that it's resting on those brackets, we can come underneath and we're just gonna attach the two together with the smaller 16-millimeter hardware. Then, we're gonna come over here and get our hardware started on this side.And now we have all of our hardware in place, we're just gonna push up, align our bumper, and then, tighten all this down, again, using a 16-millimeter socket and wrench. And then, we're gonna do the same thing over on the other side.So, now we have to wrap this up by doing a little bit of wiring in our engine bay. Like I said earlier, they are completely plug-and-play, with this wiring harness here, however, the way that I'd personally do this is I'd hardwire the fog lights to the factory harness. That way, they work on the factory switch. But what we're gonna show you today is the easiest and most reversible way to get those fog lights to work. And this is gonna be really simple. We have a couple things going on with this harness, we have two contacts here. A relay, we're gonna mount that up in the engine bay. Two plug-and-play connectors. And back here, we have our switch which we're going to feed into the cabin of our truck.Now, first things first, we're gonna mount up our contacts and they are gonna go on the terminals on the battery, black to black, red to red. We're gonna use a 10-millimeter socket to loosen up the nuts on there, apply the contacts, and then, tighten them back down.Now, for our relay, we're gonna go under this ground, right in front of the hood strut. That is going to take an 8-millimeter socket to remove that bolt.So, now we have our plug-and-play connectors left, we're gonna feed those underneath of our truck in between the battery and the radiator fan shroud. One thing to note about these, you just wanna make sure they're away from any hot or moving components. The spot we're gonna put these should be pretty good. Also, our switch, we're gonna run this along the firewall over to the driver's side, and then, we'll be able to put this into the cabin. Again, you wanna make sure the wiring is away from any hot or moving components.Now, the best place I've found for the switch is behind this rubber grommet right here. We're gonna pull that out, feed our switch through, and then, we could reinstall it from the other side. That switch is gonna come out in the footwell, and it has some adhesive on the back for you to put that wherever you want. Now, one thing that is worth mentioning is you wanna make sure that this wire is clear of all the petals. The kit does include some zip ties for your wire manage this whole thing. Last but not least, all we're gonna have to do is plug in our lights.Guys, that is gonna do it for me. Some closing thoughts here. If your bumper does need some adjustment, you can go back and loosen that up. Also your fog lights might need some adjustment as well. You definitely don't wanna blind the car in front of you, these are definitely really bright so you wanna make sure they're aimed properly. But that's gonna do it for me. It's also gonna do it for the Barricade HD off-road from bumper with LED lighting, fitting all 09 to 14 F-150s, excluding the Raptor models. As always, thank you guys for watching. Subscribe for more like this one. Keep it right here at American Trucks for all things F-150.
Subscribe to our YouTube Channel
Features, Description, Reviews, Q&A, Specs & Installation
Freight Notes. Freight items can only be shipped within the continental 48 states, no expedited methods. What is freight shipping? Your Answers are Right Here.
Fitment: 2009 2010 2011 2012 2013 2014 Details
CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
June 22, 2019
Great looking bumper
Bumper fits and looks great! You can retain your factory tow hooks. The bumper includes 3 sets of mounting brackets to mount lights on the top and inside the middle mesh. Shipping was extremely fast and the product arrived in perfect condition.Helpful (6)
Is there a way to mount a winch with this bumper?
It is not designed to accept a winch, so if it's possible it would require modification.
Are the fog lights plug and play or is wiring needed?
Wiring is required for the LED lights.
Is this more of a grey color or more of a black color?
The finish on this bumper is a matte texture black finish and looks more black than gray.
Will this work with the factory tow hooks?
This will not work with the factory tow hooks.
Can the middle vent be used to put a light bar in or are the two pods the only option for lights?
With enough modification I suppose you can do anything with the bumper, however the intended design relative to the LED's is for the pods on the outside as shown in the second product picture.
(approx) 2 Hours
Light to Moderate mechanical skill required.
What's in the Box
