Find Hoods & Hood Struts for your F-250

Hushmat Ultra Hoodliner Heat Reflective Pads; 12-Inch x 23-Inch (Universal; Some Adaptation May Be Required)

Item SD37645
Product Image
Our Price

$129.99 set of 6

Military, Medical & First Responders $6.50 Available in AT Cash Rewards.
Confirm Eligibility

Choose options to add to cart.
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program
    Join For FREE
    Loading Indicator

      Product Information

      Features, Description, Q&A, Specs & Installation

      Features & Specs

        _x000D_
      • Robust formulation designed for rugged and high-temperature engine side environments
        • _x000D_
      • Temperature resistance from -30°F to 550°F (-30°C to 290°C)
        • _x000D_
      • Proprietary self-adhesive butyl rubber compound significantly reduces road noise and vibrations for a quieter ride
        • _x000D_
      • Durable heavy-duty construction for rigorous underhood application
        • _x000D_
      • Flexible and easy to mold to complex surfaces for easy installation without special tools or harmful chemical surface preparation
        • _x000D_
      • Lightweight design with minimal impact on overall vehicle weight
        • _x000D_
      • Insulates custom painted hoods from excessive engine heat
        • _x000D_
      • Cold flexibility allows bending around a 25 mm mandrel at -30°C without cracking or loss of adhesion
        • _x000D_
      • Polymer color is black with 4 mil silver aluminum backing
        • _x000D_
      • Flexible and paintable aluminum laminate can be cut and shaped to fit various hood configurations and sizes
        • _x000D_
      • Self-extinguishing and complies with FMVSS 302 flammability standard
        • _x000D_
      • Thickness of 2.0 mm with hardness 6.5 - 9.0 mm according to ASTM D-5
        • _x000D_
      • Peel strength tested at 90-degree peel with average load reported in newtons
        • _x000D_
      • High R-value of 9 for effective thermal insulation
        • _x000D_
      • Not considered hazardous material; recommended use of gloves to avoid cuts from foil
        • _x000D_
      • Shelf life of at least 6 months when stored below 40°C
        • _x000D_
      • Specific gravity approximately 1.47 (0.60 pounds per square foot)
        • _x000D_
      • Withstands one-hour bake at 290°C without deformation, sagging, or flow in any orientation
        • _x000D_
      • Comes in six sheets measuring 12 inches by 23 inches each, totaling 12 square feet
        • _x000D_
      • Package dimensions 26 x 14 x 3 inches and weight 5 pounds
        • _x000D_
      • Country of origin: United States
        • _x000D_
      • Emissions compliance exempt
        • _x000D_
      • Fits universal; some adaptation may be required
        • _x000D_

      Description

      Heavy-Duty Thermal Insulation. The Hushmat Ultra Hoodliner Heat Reflective Pads, measuring 12 inches by 23 inches, are engineered to provide superior thermal protection under vehicle hoods. Designed to withstand extreme engine temperatures, these pads reduce heat transfer to the hood, protecting custom paint jobs while also dampening road noise and vibrations for a quieter ride.

      _x000D_

      Construction and Appearance. Made from a proprietary butyl rubber compound laminated with a flexible, paintable black polymer and backed by 4 mil silver aluminum foil, these pads feature a robust 2.0 mm thickness. This heavy-duty yet lightweight construction offers durability and ease of molding to fit complex engine bay surfaces without requiring specialized tools or chemical surface preparation.

      _x000D_

      Installation. Installation is straightforward, requiring no drilling or chemical surface preparation. The self-adhesive backing ensures quick application and strong adhesion across a wide temperature range, with a short repositioning window during installation.

      _x000D_

      Application. Designed for universal applications, some adaptation may be required to conform to various hood shapes and sizes. Suitable for virtually all makes and models and engineered for high-temperature engine compartments.

      Hushmat 50100

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) 30 Minutes

      Difficulty Level:

      Simple installation for anyone.

      Installation Guides

        No guide available for this part yet.

      What's in the Box

      • (6) Heat Reflective Pads
