AEV 4-Inch DualSport Suspension Lift System (13-18 4WD RAM 1500 w/ Air Ride)

Item R175566
Product Image
$0.00
Want $10? Write one of the first 5 reviews 4.9 AEV Suspension product ratings
Our Price

$1,648.89 set

Out of Stock

Ship to: 43215
Please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.

CONFIRM THIS FITS YOUR VEHICLE!

Select a different vehicle Help?
Update or Change Vehicle
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Loading Indicator

      Product Information

      Features, Description, Q&A, Specs & Installation

      Features & Specs

      • AEV 4-Inch DualSport Suspension Lift System
      • 4-Inch Suspension Lift System
      • Military Grade A206 T4 Aluminum Steering Knuckles (+8mm Hub Offset)
      • 4mm Stamped Steel Skid Plate (Differential Relocation & Protection)
      • Bilstein 5100 Height Adjustable Front Struts & Rear Shocks (AEV-Tuned)
      • Maintains OE Coil Springs for Factory Ride Quality and Payload Capacity
      • Digressive Valving for Optimized On/Off-Road Performance
      • Includes Low Profile Tie Rod Ends for 18" Wheel Fitment
      • Preserves OE Suspension & Steering Geometry
      • Compatible with Optional AEV ProCal Module (Sold Separately)
      • Not Compatible with Factory Air-Ride Suspension
      • Hard Installation
      • Fits 2013-2018 4WD RAM 1500 w/ Air Ride

      Description

      Premium Off-Road Suspension Upgrade. The AEV 4-Inch DualSport Suspension Lift System is engineered to elevate your RAM 1500's capability without compromising ride quality. Designed for serious off-road performance and daily drivability, this system includes AEV-tuned Bilstein 5100 shocks and maintains OE springs for consistent handling and payload retention.

      Construction and Appearance. This lift kit features military-grade A206 T4 aluminum steering knuckles with an 8mm hub offset, a 4mm stamped steel skid plate for front differential protection, and digressively valved Bilstein dampers. All components are precisely engineered to preserve factory steering and suspension geometry while providing long-lasting durability and improved articulation.

      Installation. Installation is rated hard and requires advanced mechanical knowledge or professional assistance. The system is bolt-on but involves critical components such as steering knuckles, shocks, and differential repositioning.

      Application. This AEV 4-Inch DualSport Suspension Lift System fits 2013-2018 4WD RAM 1500 with Air Ride suspension.

      AEV N0340001AB

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) 6 Hours

      Difficulty Level:

      Mechanical expertise or professional installation required.

      Installation Guides

        No guide available for this part yet.

      What's in the Box

      • (2) A206 T4 Aluminum Tall Steering Knuckles
      • (2) Low Profile Tie Rod Ends
      • (2) Front Lower Control Arm Drop Brackets
      • (2) Front Differential Relocation Brackets
      • (1) 4mm Stamped Steel Skid Plate
      • (2) Bilstein 5100 Front Struts
      • (2) Bilstein 5100 Rear Shocks
      • (2) Stainless Steel Front Brake Lines
      • (2) Front Sway Bar Endlink Extensions
      • (1) CNC Aluminum Front Driveshaft Spacer
      • (2) Rear Geometry Correction Brackets
      • (2) Rear Upper Control Arm Brackets
      • (2) Rear Coil Spring Relocation Mounts
      • (1) Rear Track Bar Bracket
      • (2) Rear Brake Line Relocation Brackets
      • (2) Rear Sway Bar Endlinks

      4.9

      Reviews of AEV Suspension Products (13)

      Brand Image

      Reviews of AEV Suspension products have an average rating of 4.85 out of 5

      Questions & Answers

      No questions about this product yet. Ask the First Question

      Will It Fit My Ram 1500

      • 3.0L V6 EcoDiesel - 14, 15, 16, 17, 18
      • 3.6L V6 - 13, 14, 15, 16, 17, 18
      • 4.7L V8 - 13
      • 5.7L V8 - 13, 14, 15, 16, 17, 18
