BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks (11-16 4WD 6.7L Powerstroke F-350 Super Duty)Find parts that fit my vehicle

Item SSD47916
$0.00
Our Price

$1,155.65 kit

Military, Medical & First Responders $57.78 Available in AT Cash Rewards.
Confirm Eligibility

CONFIRM THIS FITS YOUR VEHICLE!

Select a different vehicle Help?
Update or Change Vehicle
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

      Product Information

      Features, Description, Q&A, Specs & Installation

      Features & Specs

      • Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks
      • Front Lift Height 2.50 Inches
      • Rear Lift Blocks 4 Inches
      • NX2 Nitro Series Shocks (Front & Rear)
      • Diesel-Specific Coil Springs
      • Radius Arm Drop Brackets
      • Forged Drop Pitman Arm
      • Track Bar Relocation Bracket
      • Front Sway Bar Relocation Brackets
      • Brake Line Extension Brackets
      • Allows Clearance for Up to 35-Inch Tires
      • Maintains Factory Payload and Towing Capacity
      • Direct Bolt-On Installation
      • One-Day Installation
      • Limited Lifetime Warranty
      • Fits 2011-2016 4WD 6.7L Powerstroke F-350 Super Duty Models

      Description

      Balanced Elevation. The BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks provides a 2.50-inch front lift height. This precisely engineered elevation improves approach angles and allows for the fitment of larger tires, all while meticulously maintaining original steering geometry and drivability characteristics for a seamless integration.

      Harmonized Stance. To achieve a balanced stance, the BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks includes 4-inch rear lift blocks. These fabricated steel blocks, paired with extended U-bolts, raise the rear suspension to perfectly match the front lift, preserving proper rake and maintaining essential load-handling characteristics.

      Adaptive Comfort. The BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks is equipped with NX2 Nitro Series Shocks for both front and rear. These twin-tube, nitrogen-charged shocks feature 10-stage velocity-sensitive valving for adaptive damping across varied terrain, delivering a consistently comfortable and controlled ride.

      Optimized for Power. The BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks incorporates diesel-specific coil springs. These springs are precisely engineered to support the substantial weight of the 6.7L Powerstroke engine, ensuring proper ride height and maintaining optimal suspension balance even under heavy loads.

      Installation. Putting this BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks on your 4WD 6.7L Powerstroke F-350 Super Duty takes a day to install.

      Warranty. There is a limited lifetime warranty on this product.

      Application. The BDS 2.50-Inch Suspension Lift Kit with 4-Inch Lift Blocks and NX2 Nitro Shocks fits 2011-2016 4WD 6.7L Powerstroke F-350 Super Duty models.

      BDS BDS1510H

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) a Day

      Difficulty Level:

      Light to Moderate mechanical skill required.

      Installation Guides

        No guide available for this part yet.

      What's in the Box

      • (2) Diesel-Specific Front Coil Springs
      • (2) NX2 Nitro Front Shocks
      • (2) NX2 Nitro Rear Shocks
      • (2) Radius Arm Drop Brackets
      • (1) Forged Drop Pitman Arm
      • (1) Track Bar Relocation Bracket
      • (2) Front Sway Bar Relocation Brackets
      • (2) Brake Line Extension Brackets
      • (2) Rear Lift Blocks
      • (4) Rear U-Bolts
      • Hardware
      • Instructional Manual

      4.6

      Reviews of BDS Suspension Products (39)

      Questions & Answers

      No questions about this product yet. Ask the First Question

      Will It Fit My F-350

      • 6.7L V8 Power-Stroke - 11, 12, 13, 14, 15, 16
