Bama Rev-X Tuner by SCT with 2 Custom Tunes (17-20 3.5L EcoBoost F-150, Excluding Raptor)

Item T543251
Verify parts fit and get product recommendations.
F-150 Sales Techs: Connect Now M-F 8:30A-11P, Sat-Sun 8:30A-9P
$0.00
Our Price

$454.99 (each)

FREE Shipping Market Price $514.99 You Save 12% ($60.00) Up to 10% off for Military & First Responders! See Details

Will this fit your Vehicle?

Select a different vehicle Help?
Update or Change Vehicle
Ship to: Ashburn - 20149
Sorry, please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

      Product Videos

      Hey, guys. Adam here with americantrucks.com and today we're taking a closer look at and installing as well as dyno-testing the Bama Rev-X by SCT Tuner with two Custom Tunes available for the '17 to '18 3.5-liter EcoBoost F150. Now, before we jump into the details of the Rev-X and the two tunes from Bama Performance, what do you say we head right over to the dyno graph and talk about the results? Now, we have our 17 3.5 Eco F150 on the dyno here. We have 35-inch all-terrains on there along with 93 octane in the tank, which is worth mentioning because that does affect results and it has a 10-speed. We pulled that 10-speed in fifth gear to avoid hitting the speed limiter in the one-to-one gear of seven. We walked away with a baseline number of 288 horsepower, 364-pound-feet of torque at the rear wheels, uploaded our Bama 93 octane tune, ran it under the same conditions, and walked away with 364 horsepower and 416-pound-feet of torque at the rear wheels. That's peak gains of 76 horsepower and 52-pound-feet of torque at the rear wheels, and those numbers look really, really good on our EcoBoost, but the curve gains are even more impressive. We're seeing curve gains of as much as 104 horsepower and 100-pound-feet of torque at the rear wheels over stock. Those curve gains are insane, which is a little bit more than what we expected from this EcoBoost. So that's really, really good. And we're seeing those gains at the top end of the RPM band right around 5,400 RPMs. Adding this tune and picking up so much torque at the low end is really making a difference to drivability.So as you saw from the dyno graph, we made amazing gains with the Bama tune here and that's the 93 octane out of the two that's given to you from Bama. On the device, we'll be able to take advantage of the 87 octane and the 93 race tune. Now, the 87 options are gonna be a good choice for any daily driver out there or weekend warrior looking to just get a little bit more out of your truck, a little bit more throttle response and acceleration to combat some of the sluggish feel that you'd get, especially with larger wheels and tires. Now, the 93 performance or the 93 race tune from Bama is gonna be the way to go if you want all out performance to really maximize your truck's potential. Bama takes a number of things in consideration like timing, spark, air-fuel ratio, and the drive-by-wire delay, which will be altered in the tune here to give you a lot more out of your truck. Now, the drive-by-wire delay is essentially the delay in time between hitting your gas pedal and your throttle body opening up and your truck getting going off the line. So with that delay removed or minimized here, you'll definitely feel a lot stronger getting off the line and as you saw from our graph here, that 93 tune is making a ton of torque down-low and that torque curve is staying very consistent through the RPM band. So you can expect that torquey feel to really be something that changes your driving experience on a day-to-day basis, really at all times.Now, aside from the tunes themselves, there's a number of other things to take advantage of on your Rev-X device. One of the big things I like to talk about here is the gauges and data log screen. You can monitor live engine vitals on the fly within arm's reach at any time in the driver seat. Now, the gauges screen here allows you to monitor up to eight different parameters all at once. Things like air-fuel ratio, coolant temp, boost in PSI, which is a big thing for these turbo trucks as well as intake air temperatures, and a number of other things. Now, you can also record the data log performance here on the device to communicate that back to your tuner. So if you wanna see possible revisions or maybe improve upon your truck's performance, you can communicate that back to Bama using your data log recording capabilities here. There's also a DTC code reader. You can read and clear diagnostic trouble codes or the check engine light right from the device without needing any other OBD 2 module. No need to take it to AutoZone or any other store like that to have them read it for you. You can do it yourself. You also have WIFI capability, cloud access, which basically means you can wirelessly send and receive tune files and data log files without needing to plug it into your computer or laptop. All you need is a WIFI connection. You can wirelessly update the software and firmware versions and there's a couple of other settings I'll walk you through in just a minute.The tuner itself here comes in right around 430 bucks, and that's combined with the two tunes from Bama. It's also worth noting, anytime you pick up a Bama tune combined with a handheld tuner like this or the X4, for example, you're automatically enrolled in the Bama Free Tunes for Life program. Anytime that you need a revision to the tune, so if you add a cold air intake, or a cat-back, or really any performance mod, you can get the tune rewritten to include that and maximize his performance for free for the lifetime that you have your device and truck paired. So that's a really big value to take advantage of. We always know that we're pretty much never done modding these trucks, so that can really come in handy and save you some money in the long run. Now, at the install, I'm gonna give one out of three wrenches on our difficulty meter. Anybody can tackle this in the driveway at home with about 30 minutes from start to finish. I'm gonna walk you through the whole tuning process and I'll show you how to use all the features I just mentioned. What do you say we get to it?First up here, guys, grab your Rev-X and the OBD 2 harness included in the kit, you're gonna plug this guy into the OBD 2 port located under the driver side dash. Now, that's gonna be right next to your emergency brake there, so we're gonna plug that guy in. The other end is gonna plug right into the top of your Rev-X. Now we can hop in and get to tuning. All right, so once you have your device plugged in, I'm gonna leave it right here on our steering wheel, show you guys the process here for tuning your vehicle. So right from the main menu, you'll have Program Vehicle, Gauges, Datalog, Vehicle Functions, Vehicle Info, Device Info, and Device Settings. You wanna select Program Vehicle to actually flash a tune. Confirm your VIN number, press Confirm. From here, right out of the box, your device will probably need to be updated. We've already updated ours. If you haven't done so already, you wanna go over and press Continue. Now for that, you will need to connect to WIFI, so be within range of a WIFI network. And again, we've already taken care of it. So we're gonna select Skip. If you've already updated yours, you can do that as well. All right, so while we did do a software update, we're now doing a firmware update on our device, which sometimes can happen right after the software. So allow it to load zero to 100 as many times as it needs. Looks like two updates as what's happening here and then we'll move into tuning.All right. So once it's complete, you can press Okay. Internet required. Again, you'll need to connect to a WIFI network. At this point, it would prompt you to connect to WIFI. Now, ours is already connected, so it should just verify files and move forward. All right, now at this point, the Rev-X does have cloud capabilities. So if your tuner, in this case Bama, sent you your tune file on the cloud instead of it via email, you'll be able to press Continue, sync the tune from the cloud to your device and then move over to flashing. Now, ours is physically loaded to the device via email, so we're gonna hit Skip, but that all depends on how it was sent to you from Bama. Now, street use, you're gonna press Continue. Make sure your key is in the ON position and press Continue again. At this point, you'll be able to select your tune. Now, you may have multiple from your tuner. We're only focusing on the 93 performance or otherwise known as 93 race tune. So that's the only thing we have loaded it in the custom tunes section of this menu. Now, if you wanna select your 87 tune, you can do that now as well. It just depends on what you either pulled from the cloud or loaded to the device via email on your computer. So we're gonna select 93 performance. There are additional options to change in the tune. I'll select Change just to show you guys what that looks like. So let's hit Change again. You have Spark, Axle Ratio, Tire Revs Per Mile, Speed Limiter, Rev Limiter, so many different options here that you can play with. If you do not want to edit any of these, you don't have to. We're actually gonna leave all of these the same and just go with the tune that was sent to us.All right. So we're gonna hit Continue. As you can see at this point, it's applying options, which basically means it's applying any of those changes that you made to the tune, compiling that together. From here, it will move into saving your stock tune to the device, so anytime you wanna revert back to your factory Ford tune, you can do so right on the device using the same menu options. Return to Stock will appear once it's been flashed to aftermarket, and then from there it will move in to actually flash the vehicle. During this process, of course, you don't wanna unplug the device or turn the key off unless it's prompting you to do so on the screen. Sometimes it may tell you to turn the key off and then press Continue and then back on and press Continue. So if it does that, follow those directions. But if not, let it do its thing.All right. So once it moves into the next phase, it's gonna write the tune, which will be again loading zero to 100. The lights on the dash may turn off. Just make sure you're not turning your key off. Just follow the instructions on the screen, don't unplug your device, and we'll come back when it's done. All right. So here we're being told to turn the key off and then wait for instruction, back on. Same thing. All right. And there you have it, programming complete, you can hit Done. Takes you right back to the main menu.All right. So next, I wanna take you through some of the Rev-X's features here aside from programming vehicle. Under that, you'll see Gauges and Datalog. Now, this is gonna be a good screen for the guys who wanna monitor live engine vitals on the fly at all times. All you'll have to do is make sure the key is on, press Continue. All this is gonna do is really connect to your ECU, give you your configuration property or vehicle, and it'll track as many of these as you'd like at the same time. Now, you can track up to eight of them and they're all interchangeable. So right from the default here, we have all eight displayed. There are little gauges, four on each side going vertically. So what you can do is let's make it a little bit easier to read. You can go to the right here, we can go to Select Gauge Layout, you can change what this guy will look like. So let's go with something very simple. We'll just track two gauges at once, a lot bigger and easier to read. So we have boost in PSI up top, control module voltage on the bottom. Now, because we're in an EcoBoost, we got some turbos going on. What we want is boost, right? So most people will track boost, but say we don't want control module voltage, we'll select that guy, change the item. Say we wanna track intake air temperature instead, select it, go over and hit Approve, and it replaces that gauge. So it's super easy to use. It's very responsive and there's a lot to choose from. So if we didn't just want two options, you go to the right, go down to gauge layout, you already saw eight, you can track two, three, four, there's five here, six, and then eight. So let's see four. And there you have it. And again, you can change any of these to whatever you want out of the list menu.Now, if you wanted to record a datalog, you can start Record Data, that'll record the engine performance and you can communicate that back to your tuner or you can just have it for your records and that can be saved directly onto the device and it can be communicated back into the cloud. So we can hit Stop Datalog and it'll take us back to the main menu. Now, under that, there's Vehicle Functions, Read DTC and Clear. Now, DTC is the diagnostic trouble code, your check engine light, that guy comes on, you can plug this device in, go to this menu, read the code. You can clear the code. And then special functions, most people won't touch, things like cam relearn, so what we're gonna do is go back to the main menu.Finally, we have Vehicle Info which will give you your VIN number in ECU strategy code along with some of the other vehicle parameters. Device Info is gonna be software and firmware versions, your married status, how many unlocks you have left with the device, so say you wanna use this device but on a different vehicle, you can have it unlocked from the vehicle that you have. Every time you return the vehicle to stock, it unlocks it from the device. You can then pair it to a new vehicle and you have up to five different times you can do that and that information will be stored in Device Info. Now, Device Settings here has things like check for update and WIFI, which kinda go hand in hand. If you're in range of a WIFI network, you can connect to that and get wireless updates to the device. Anytime SCT puts out a software update, it's good to check here. Now, cloud file sync is something unique to the Rev-X as opposed to the X4 option. Basically this makes things wireless. If you're getting tune revisions, if you're sending or receiving datalog files, you can do it all wirelessly via the cloud and again, you'll need WIFI access for this, but that'll eliminate the need to plug it into a laptop or computer. You can upload, again, datalog to the cloud. You can also upload your stock file to the cloud to save.And then there's regular settings like the brightness and Day and Night mode. You can change your theme. Default is dark red, but you can change it to light blue. There's also light red, just really simple things to customize it to your own liking. And then finally, there is a little beep here. When you hit a button, you can change that, turn that off. Finally, the Start function that I think is gonna be most important for guys here in the Device Settings menu is the Startup mode. So you could have it immediately load up to the Gauges and Datalog menu if you find yourself using that more often than not. Now, if you are, you may be picking up a windshield mount or a vent gauge mount to mount this guy within arm's reach. If that's the case, I'd recommend turning this on. That way you can just leave it plugged in at all times and as soon as you turn your vehicle on and load this up, it immediately goes to Gauges. So I think that's really useful. From there, we'll hit Exit, takes you right back to the main menu and that's your Rev-X device.Well, guys, that's gonna wrap up my review, install and dyno test for the Bama Rev-X by SCT Tuner with two Custom Tunes for the '17 to '18 3.5 F150. If you wanna get yours, you can do so right here to americantrucks.com.

      Product Information

      Features, Description, Reviews, Q&A, Specs & Installation

      Features

      • Improves Horsepower, Torque and Performance
      • Guaranteed Maximum, Safe and Reliable Power
      • Includes (2) Custom Bama Tunes - $150 Value
      • Datalogging with Unlimited Free Tune Revisions for Life
      • Download Tunes & Get Device Updates via Wi-Fi, No Computer Required
      • OBD-II Data Logging and Monitoring
      • Diagnostics Tool - Reads and Clears DTC Trouble Codes
      • Holds Up to 10 Custom Tunes
      • What Does BAMA Offer Tunes For? CLICK HERE
      • What More Information about the Free Tunes for Life Program? CLICK HERE
      • Custom Tunes Take 2-3 Business Days to be Written
      • For use with 2017-2020 Ford 3.5L EcoBoost F-150 Models, Excludes Raptor

      Description

      Bama Custom Tuning at AmericanMuscle. Power. Performance. Personalized. Proven
      • Buy this Tuner & Submit your F-150's Info
      • A Bama Performance Calibrator will write custom tunes just for your F-150 & Mods
      • Load 'em on your F-150 and GO!
      • As you add new mods, Bama will update your tune files for FREE! That's right, Free Tunes for Life!

      More Power and Better Performance. Now you can add dyno proven gains in power and torque, as well as improve the overall performance of your 2017-2020 3.5L V6 EcoBoost F-150 with a Rev-X Programmer that includes 2 Bama Custom Tune Files. By optimizing the air/fuel ratio, adjusting ignition timing and tweaking variable cam timing, a Bama Performance Custom Tune will squeeze out the extra power Ford left on the table. From the factory, Ford programs their vehicles to cater to the needs of the daily driver, not the performance enthusiast who adds aftermarket bolt-on modifications in search of more power. If you have added a cold air intake, throttle body, exhaust or other performance upgrades, you'll need a custom tune to see the full power potential that these aftermarket bolt-on modifications can make.

      Free Tunes for Life! Every customer that purchases a Bama Performance Rev-X Tuner is enrolled in the Free Tunes for Life program. Any time that you make additional mods to your vehicle, our team of certified Bama Calibrators will create new tunes for you. Just send us a list of the part or parts you've added and we'll upload your new tune files to the cloud.

      Two Custom Bama Tunes. When you order a Rev-X Tuner by SCT, you aren't just getting a tuner. You're getting the tuner and two dyno-tested custom tunes that are written specifically for your F-150 and your particular modifications by a Bama Performance calibrator. Bama even includes datalog reviews to ensure your vehicle is fully optimized.

      Performance / Towing (87-93 Octane) - The Performance/Towing Tune offers a seamless blend of power and performance that will improve the overall driving experience of your F-150. This tune improves vehicle acceleration and increases power throughout the entire RPM band. The revised transmission settings will provide more aggressive shifts. This tune is suggested for the day to day daily driver, who is concerned about low end power for towing, as well as performance for passing on the highway. This tune is available for 87, 89, 91 and 93 octane levels.

      Economy (87-93 Octane) - The Economy Tune is designed for fuel savings just as the name implies. This Tune is for those F-150 owners who are concerned about fuel economy and want to increase gas mileage, but still want better than factory performance. This tune is available for 87, 89, 91 and 93 octane levels.


      Wi-Fi Updates and Cloud Tuning. The Rev-X Tuner by SCT is Wi-Fi capable meaning it will always be up to date. Once setup with your Wi-Fi password, the Rev-X will download the latest firmware updates via the internet. Besides firmware updates, your Rev-X can also download your custom Bama tune files via the cloud, reducing the hassles of transferring files from your PC to your Rev-X device.

      Data Logging and Monitoring. The Rev-X Tuner by SCT makes it easy to read the Built-In Data Logging and/or the Real Time Data, so you can view popular sensor data such as EGT, Air/Fuel Ratio or any other 0-5 Volt source. You can even customize the monitoring capability of your Rev-X using device's free Livelink software.

      Diagnostics Tool. The Rev-X Tuner can also be used as a diagnostic code reader. Save yourself hundreds of dollars each year by reading and clearing your own Diagnostic Trouble Codes (DTCs) rather than paying a dealer to do the same. It's as easy as a few simple steps.

      Easy to Load; Easy to Restore. When you load your custom tune on the vehicle, the tuner automatically stores your vehicle's factory settings. To return the vehicle to its factory settings, just plug the tuner back in, select the option to restore the factory settings, and you're done. This is ideal for visiting dealerships for warranty work.

      Not CARB Certified. The SCT Rev-X Tuning Device is not CARB certified, therefore it is not legal for use in California or any other state adopting California emission standards. Not legal for use on pollution controlled motor vehicles; intended for off road use only.

      Application. This Bama Rev-X Tuner by SCT with 2 Custom Tune Files by Bama Performance is specifically designed for 2017-2020 Ford F-150 EcoBoost models equipped with the turbocharged 3.5L V6 engine, excludes SVT Raptor.

      **Please Note: The Rev-X Performance Programmer ships blank from AmericanTrucks. Your custom tune files will be available for download via the cloud when your tuner arrives.

      It's highly recommended to download Free LiveLink and Updater Software. The LiveLink Application is used to view, data log, record and playback your Mustang's PCM data on a laptop computer. The Updater Application lets you update your device's Firmware, Tune Revision or to load Custom Tunes onto your device. Requires Windows Vista/7/8/10 and an internet connection.

      Bama Performance

      Shop All Truck Parts And Accessories

      Shop All Truck Tuners

      Fitment:

      Details

      Bama T543251

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      What's in the Box

      • (1) Rev-X Device
      • (1) HDMI/OBDII Interface Cable
      • (1) Micro USB Cable
      • (2) Bama Performance Custom Tune Files - via email
      4.5

      Customer Reviews (19)

        Questions & Answers

        10 More Questions

        Will It Fit My F-150

        • 3.5L V6 EcoBoost - 17, 18, 19, 20
