Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight; Spot Beam; Clear (Universal; Some Adaptation May Be Required)
Item S175379
Our Price
$524.95 each
Military, Medical & First Responders
$26.25 Available in AT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Reviews, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting _x000D_
- Lighting Quantity 6 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Product Type LP6 Pro LED Light Pod _x000D_
- Secondary Brightness 1972 Lumens _x000D_
- Secondary Light Quantity 4 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology IPT _x000D_
- Secondary Wattage 15 W _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Wattage 103.5 W _x000D_
- Wiring Harness Included No _x000D_
- Amperage Rating 7.5 A _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Backlight Amperage Rating 0.3 A _x000D_
- Backlight Wattage 4.14 W _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 11,225 Lumens _x000D_
- Description Spot Clear _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Exceeds MIL-STD810G Mil-Spec Testing _x000D_
- IK10 Compliant Mechanical Impact Testing _x000D_
- IP69K Waterproof Up To 9ft and Pressure Washable _x000D_
- Depth 3.2 Inches _x000D_
- Height 6.5 Inches _x000D_
- Length 6.5 Inches _x000D_
- Weight 4.2 Pounds _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 6 to 7.75 Inch |
Description
Powerful Spot Illumination. The Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight; Spot Beam; Clear lens is engineered to provide high-intensity illumination for off-road and auxiliary lighting needs. Featuring a focused spot beam pattern, it enhances long-distance visibility, ideal for trail driving and supplementing existing lights for superior road and trail illumination.
_x000D__x000D_Construction and Appearance. Built with a powder-coated cast aluminum housing and a hardcoated polycarbonate lens, the LP6 Pro offers durability with a sleek black finish. These robust materials ensure resistance to mechanical impacts and harsh environmental conditions, supported by MIL-STD810G compliance and an IK10 impact rating for reliable, rugged performance.
_x000D__x000D_Installation. Installation is user-friendly with included stainless steel mounting hardware. It requires basic mechanical skills and typically does not need additional drilling, facilitating an efficient setup process.
_x000D__x000D_Warranty. This product is backed by a limited lifetime warranty, providing purchase protection and peace of mind.
_x000D__x000D_Application. Fits universal applications; some adaptation may be required.
Baja Designs 270014
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LED Auxiliary Light Pod
- Mounting Bracket
- Hardware
