Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight; Spot Beam; Clear (Universal; Some Adaptation May Be Required)

Item HG35403
Our Price

$524.95 each

Military, Medical & First Responders $26.25 Available in AT Cash Rewards.
Confirm Eligibility

Choose options to add to cart.
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program

      Product Information

      Features, Description, Reviews, Q&A, Specs & Installation

      Features & Specs

        _x000D_
      • Lens Color Clear
      • _x000D_
      • Lens Material Hardcoated Polycarbonate
      • _x000D_
      • Light Quantity 1
      • _x000D_
      • Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting
      • _x000D_
      • Lighting Quantity 6
      • _x000D_
      • Lighting Technology LED
      • _x000D_
      • Lighting Type Forward Projecting
      • _x000D_
      • Mounting Hardware Included Yes
      • _x000D_
      • Mounting Hardware Material Stainless Steel
      • _x000D_
      • Overvoltage Protection Built-In
      • _x000D_
      • Product Type LP6 Pro LED Light Pod
      • _x000D_
      • Secondary Amperage Rating 1.000 Amps
      • _x000D_
      • Secondary Brightness 1972 Lumens
      • _x000D_
      • Secondary Light Quantity 4 LEDs
      • _x000D_
      • Secondary Lighting Technology LED
      • _x000D_
      • Secondary Lighting Type Integrated Peripheral Technology (IPT)
      • _x000D_
      • Secondary Wattage 15 Watts
      • _x000D_
      • Terminal Connector DT06-4S Deutsch
      • _x000D_
      • Terminal Type Mating Connector
      • _x000D_
      • Wattage 103.5 Watts
      • _x000D_
      • Amperage Rating 7.5 Amps
      • _x000D_
      • Average Rated Life 49,930 Hours
      • _x000D_
      • Backlight Amperage Rating 0.3 Amps
      • _x000D_
      • Backlight Wattage 4.14 Watts
      • _x000D_
      • Beam Pattern Spot
      • _x000D_
      • Bezel Material Powder Coat Cast Aluminum
      • _x000D_
      • Brightness 11,225 Lumens
      • _x000D_
      • Description Spot; Clear
      • _x000D_
      • Housing Color Black
      • _x000D_
      • Housing Material Powder Coat Cast Aluminum
      • _x000D_
      • Standards Compliance Exceeds MIL-STD810G (Mil-Spec Testing)
      • _x000D_
      • Impact Resistance IK10 Compliant (Mechanical Impact Testing)
      • _x000D_
      • Water Resistance IP69K (Waterproof Up To 9ft & Pressure Washable)
      • _x000D_
      • Depth 3.2 Inches
      • _x000D_
      • Height 6.5 Inches
      • _x000D_
      • Length 6.5 Inches
      • _x000D_
      • Weight 4.2 Pounds
      • _x000D_
      • Fits Universal; Some Adaptation May Be Required
      • _x000D_

      Description

      Powerful LED Lighting. The Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight delivers an intense 11,225 lumens output with a focused 8-degree spot beam for long-distance illumination. Designed for off-road and show usage, this light pod offers high visibility and peripheral lighting through Integrated Peripheral Technology (IPT), enhancing driver awareness on demanding trails and roadways.

      _x000D__x000D_

      Construction and Appearance. Crafted with a powder-coat cast aluminum housing and a hardcoated polycarbonate lens, the pod offers rugged durability and protection against harsh environmental elements. It features a black finish and stainless steel mounting hardware, contributing to a sleek aesthetic and reliable performance. The product exceeds MIL-STD810G standards for military-spec testing, is IK10 compliant for mechanical impact resistance, and rated IP69K waterproof for up to 9 feet and suitable for pressure washing.

      _x000D__x000D_

      Installation. Installation is straightforward with included stainless steel mounting hardware and typically requires no drilling unless customized mounting is desired. The light uses a DT06-4S Deutsch connector for secure wiring connections.

      _x000D__x000D_

      Warranty. The product comes backed by a limited lifetime warranty, ensuring long-term protection against defects.

      _x000D__x000D_

      Application. Fits universal applications; some adaptation may be required to integrate with specific vehicle configurations.

      Baja Designs 270014

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) 1 Hour

      Difficulty Level:

      Simple installation for anyone.

      Installation Guides

        No guide available for this part yet.

      What's in the Box

      • (1) LED Auxiliary Light Pod
      • Mounting Bracket
      • Hardware
