Hushmat Ultra Hoodliner Heat Reflective Pads; 12-Inch x 23-Inch (Universal; Some Adaptation May Be Required)

Item FR29200
Product Image
Our Price

$129.99 set of 6

Military, Medical & First Responders $6.50 Available in AT Cash Rewards.
Confirm Eligibility

Choose options to add to cart.
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program
    Join For FREE
    Loading Indicator

      Product Information

      Features, Description, Q&A, Specs & Installation

      Features & Specs

        _x000D_
      • Robust formulation designed for rugged and high-temperature engine-side environments
        • _x000D_
      • Rated from -30°F to +550°F temperature range
        • _x000D_
      • Proprietary self-adhesive butyl rubber compound significantly reduces road noise and vibrations for a quieter ride
        • _x000D_
      • Durable, heavy-duty construction designed for the rigor of underhood application
        • _x000D_
      • High-temperature resistance up to 550°F
        • _x000D_
      • Flexible and easy to mold to complex surfaces offers easy installation without special tools or harmful chemical surface preparation
        • _x000D_
      • Lightweight design offers minimal impact on overall vehicle weight
        • _x000D_
      • Insulates custom painted hoods from excessive engine heat
        • _x000D_
      • Cold flexibility: can be bent around a 25 mm mandrel at -30°C with no cracking or loss of adhesion
        • _x000D_
      • Black polymer top layer with aluminum 4 mil silver backing
        • _x000D_
      • Flexible and paintable aluminum laminate can be cut and shaped to fit various hood configurations and sizes for versatility
        • _x000D_
      • Self-extinguishing flammability tested per FMVSS 302
        • _x000D_
      • Thickness of 2.0 mm
        • _x000D_
      • High peel strength tested at 90-degree peel, maintaining adhesion under stress
        • _x000D_
      • R-value of 9 provides effective thermal insulation
        • _x000D_
      • Safe material not considered hazardous; gloves recommended to avoid foil cuts
        • _x000D_
      • Shelf life of at least 6 months when stored at 40°C or less
        • _x000D_
      • Specific gravity approximately 1.47 (0.60 pounds per square foot)
        • _x000D_
      • Resistant to bake at 290°C for 1 hour without deformation
        • _x000D_
      • Package includes 6 sheets, each measuring 12 inches by 23 inches
        • _x000D_
      • Package dimensions: 26 x 14 x 3 inches
        • _x000D_
      • Package weight: 5 pounds
        • _x000D_
      • Country of origin: United States
        • _x000D_
      • Emissions compliance exempt
        • _x000D_
      • Fits universal; some adaptation may be required
        • _x000D_

      Description

      High-Performance Hoodliner Insulation. The Hushmat Ultra Hoodliner Heat Reflective Pads, measuring 12 inches by 23 inches, provide superior thermal insulation designed specifically for installation on the engine side of vehicle hoods. These pads effectively reduce excessive engine heat transfer and road noise, protecting custom painted hoods and enhancing driver comfort through sound and thermal management.

      _x000D__x000D_

      Construction And Appearance. Constructed from a flexible and paintable aluminum laminate with a black polymer top layer and 4 mil silver aluminum backing, the pads combine durability with aesthetic versatility. The 2.0 mm thick butyl rubber compound is engineered to withstand temperatures up to 550°F, ensuring robust performance in demanding underhood environments.

      _x000D__x000D_

      Installation. Installation is straightforward, requiring no special tools or harmful chemical surface preparations thanks to the proprietary self-adhesive butyl rubber compound. The pads easily conform to complex hood surfaces, offering user-friendly application suitable for both professionals and enthusiasts.

      _x000D__x000D_

      Application. Designed to fit universally across most vehicle hoods, the product may require some adaptation to accommodate specific hood shapes and configurations, ensuring optimal coverage and performance.

      Hushmat 50100

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) 30 Minutes

      Difficulty Level:

      Simple installation for anyone.

      Installation Guides

        No guide available for this part yet.

      What's in the Box

      • (6) Heat Reflective Pads
