Find Fog Lights for your Yukon

Diode Dynamics SS3 Max ABL Type CH LED Fog Light Kit; White SAE Fog (15-20 Yukon)Find parts that fit my vehicle

Item GY1443
Product Image
184 Reviews of Diode Dynamics
Our Price

$719.95 kit

Military, Medical & First Responders $36.00 Available in AT Cash Rewards.
Confirm Eligibility

CONFIRM THIS FITS YOUR VEHICLE!

Select a different vehicle Help?
Update or Change Vehicle

Item Options

Diode Dynamics SS3 Security Hardware Kit
Diode Dynamics SS3 Security Hardware Kit
+ $39.95
Yes No
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program
    Join For FREE
    Loading Indicator

      Product Information

      Features, Description, Q&A, Specs & Installation

      Features & Specs

        _x000D_
      • Advanced TIR Optics Provide High Efficiency And Focus
        • _x000D_
      • SAE-Compliant Road-Legal Output
        • _x000D_
      • Includes One-Piece Molded Bezel For Factory-Style Appearance
        • _x000D_
      • Plug And Play Installation, No Modification Needed
        • _x000D_
      • Durable Powder-Coated Aluminum Housing
        • _x000D_
      • Engineered And Assembled In USA
        • _x000D_
      • Peak Beam Intensity 18,000 Cd
        • _x000D_
      • Illuminance 180 Lux At 10m
        • _x000D_
      • Measured Output 3,500 Lumens
        • _x000D_
      • Raw Output 7,920 Lumens
        • _x000D_
      • Output Color 6000K White
        • _x000D_
      • Main Beam Power 38.5 Watts
        • _x000D_
      • Main Beam Current 3 Amps @ 12.8V
        • _x000D_
      • Backlight Power 0.4 Watts
        • _x000D_
      • Backlight Current 0.03 Amps @ 12.8V
        • _x000D_
      • Operating Voltage 9-30V
        • _x000D_
      • Beam Angle Fog 80° x 8°
        • _x000D_
      • Polarity Specific
        • _x000D_
      • Operating Temperature -40°C To 85°C (-40°F To 185°F)
        • _x000D_
      • LED Emitters Luxeon Z ES, Cree XP-L HI, Osram Boost HX
        • _x000D_
      • Connectors Deutsch DT Input
        • _x000D_
      • Driver Features Constant Current
        • _x000D_
      • Materials Polycarbonate Lens, Aluminum Casting, Rubber Gasket
        • _x000D_
      • Cooling Passive With Pin-Fin Heatsink
        • _x000D_
      • Compliance Ratings SAE J575 Durability Test, SAE J583 Foglamp Beam Pattern
        • _x000D_
      • Intrusion Ratings IP69K Waterproof, High Pressure Resistant
        • _x000D_
      • Unit Weight 2.075 Lb
        • _x000D_
      • Product Weight 4.15 Lb
        • _x000D_
      • Shipped Weight 4.7 Lb
        • _x000D_
      • Fits 2015-2020 Yukon
        • _x000D_

      Description

      High-Performance Lighting. The Diode Dynamics SS3 Max ABL Type CH LED Fog Light Kit in White SAE fog color delivers superior illumination with high-intensity LED pods designed to enhance visibility in adverse conditions. This fog light kit provides a focused, bright beam pattern that improves road safety while maintaining a factory-style appearance.

      _x000D__x000D_

      Construction and Appearance. Built from durable powder-coated aluminum with a polycarbonate lens, this kit is engineered to withstand harsh environments. The encapsulated design includes custom TIR optics that act as the main lens, ensuring maximum light efficiency and reduced glare, all finished with a sleek and durable coating.

      _x000D__x000D_

      Installation. Designed for straightforward plug-and-play installation, this kit requires no modifications or drilling, and mounts directly in place of factory fog lights using custom brackets. Installation typically takes between 30 and 60 minutes using basic tools.

      _x000D__x000D_

      Warranty. This product includes a limited lifetime warranty, providing long-term reliability and customer confidence.

      _x000D__x000D_

      Application. Specifically designed to fit the 2015-2020 Yukon, this kit replaces the factory fog light assemblies with an OEM-quality clean look while delivering enhanced lighting performance.

      Diode Dynamics DD7307

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) 2 Hours

      Difficulty Level:

      Light to Moderate mechanical skill required.

      Installation Guides

      What's in the Box

      • (2) Fog Lights
      • (1) Wiring Harness
      • Mounting Hardware
      • Instruction Manual
