Baja Designs 50-Inch OnX6 Hybrid LED/Laser Light Bar; Hybrid Spot Beam; Clear (Universal; Some Adaptation May Be Required)
Item FR29503
Our Price
$4,222.95 each
Military, Medical & First Responders
$211.15 Available in AT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Hybrid Spot Beam Pattern _x000D_
- Clear Lens Color _x000D_
- Available in Sizes 10 Inch, 20 Inch, 30 Inch, 40 Inch, and 50 Inch _x000D_
- Forward Projecting Lighting Type _x000D_
- Powered by 2 Laser Chips and 4 Next Generation LEDs per 10-Inch Segment _x000D_
- Bezel Made of Billet Machined Aluminum _x000D_
- Housing Constructed from Aircraft Grade Aluminum with Mil-Spec Hard Anodize Finish _x000D_
- Hardcoated Polycarbonate Lens Material _x000D_
- Stainless Steel Mounting Hardware Included _x000D_
- Built-In Overvoltage Protection _x000D_
- Rated Brightness Approximately 3750 Lumens per 10-Inch Segment _x000D_
- Average Rated Life Around 49,930 Hours _x000D_
- Exceeds MIL-STD810G Durability Standards _x000D_
- IK10 Compliant Impact Resistance _x000D_
- IP69K Waterproof Rating (Submersible Up to 9 Feet and Pressure Washable) _x000D_
- Wattage Approximately 99.36 Watts _x000D_
- One Light Quantity Per Unit _x000D_
- Multiple Lighting Quantity Depending on Size (E.g., 6 Lights for 10 Inch, Up to 30 Lights for 50 Inch) _x000D_
- Wiring Harness Not Included _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Patented Design (Patent No. 10,641,472) _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Light Bar Width | 50 Inch and Up |
Description
Advanced Lighting Solution. The Baja Designs 50-Inch OnX6 Hybrid LED/Laser Light Bar with Hybrid Spot Beam and Clear Lens combines next-generation LEDs with laser technology, dramatically increasing throw distance by 30-40% compared to previous models. Ideal for high-speed off-road use, this light bar effectively illuminates target zones up to Zone 51, enhancing visibility and safety during nighttime driving and challenging terrain navigation.
_x000D__x000D_Construction and Appearance. Crafted from aircraft-grade aluminum with a Mil-Spec hard anodized finish, this light bar features a billet machined aluminum bezel and a hardcoated polycarbonate lens for exceptional durability and resistance to environmental elements. Its sleek black housing and clear lens provide a professional, rugged look suited for demanding off-road conditions.
_x000D__x000D_Installation. Installation is straightforward with included stainless steel mounting hardware, requiring minimal modifications. Drilling is generally not required, making this a practical upgrade for a wide variety of vehicles.
_x000D__x000D_Warranty. Supported by a limited lifetime warranty for reliable purchase protection.
_x000D__x000D_Application. This product fits universally and may require some adaptation depending on the vehicle and mounting preferences.
Baja Designs 455007
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) Light Bar
