Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight; Spot Beam; Clear (Universal; Some Adaptation May Be Required)

Item S560309
Our Price

$524.95 each

Military, Medical & First Responders $26.25 Available in AT Cash Rewards.
Confirm Eligibility

Choose options to add to cart.
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program

      Product Information

      Features, Description, Reviews, Q&A, Specs & Installation

      Features & Specs

      • Lens Color Clear
      • Lens Material Hardcoated Polycarbonate
      • Light Quantity 1
      • Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting
      • Lighting Quantity 6
      • Lighting Technology LED
      • Lighting Type Forward Projecting
      • Mounting Hardware Included Yes
      • Mounting Hardware Material Stainless Steel
      • Overvoltage Protection Built-In
      • Product Type LP6 Pro LED Light Pod
      • Secondary Amperage Rating 1.000 A
      • Secondary Brightness 1972 Lumens
      • Secondary Light Quantity 4 LEDs
      • Secondary Lighting Technology LED
      • Secondary Lighting Type Integrated Peripheral Technology (IPT)
      • Secondary Wattage 15 W
      • Terminal Connector DT06-4S Deutsch
      • Terminal Type Mating Connector
      • Universal Or Specific Universal
      • Wattage 103.5 W
      • Wiring Harness Included No
      • Amperage Rating 7.5 A
      • Average Rated Life 49,930 Hours
      • Backlight Amperage Rating 0.3 A
      • Backlight Wattage 4.14 W
      • Beam Pattern Spot
      • Bezel Material Powder Coat Cast Aluminum
      • Brightness 11,225 Lumens
      • Description Spot; Clear
      • Housing Color Black
      • Housing Material Powder Coat Cast Aluminum
      • Standards/Compliance Durability Exceeds MIL-STD810G (Mil-Spec Testing)
      • Standards/Compliance Impact Resistance IK10 Compliant (Mechanical Impact Testing)
      • Standards/Compliance Water Resistance IP69K (Waterproof up to 9ft & Pressure Washable)
      • Depth 3.2 Inches
      • Height 6.5 Inches
      • Length 6.5 Inches
      • Weight 4.2 Pounds
      • Fits Universal; Some Adaptation May Be Required

      Description

      High-Performance Lighting. The Baja Designs LP6 Pro LED Auxiliary Light Pod with Red Backlight; Spot Beam; Clear delivers exceptional brightness of 11,225 lumens with a 200-degree light spread powered by advanced Integrated Peripheral Technology (IPT). Designed for off-road and auxiliary lighting applications, it ensures enhanced visibility and safety in challenging driving conditions.

      Construction and Appearance. This light pod is constructed from powder-coated cast aluminum for superior durability and impact resistance, finished in a sleek black color to resist corrosion and wear. The lens is made of hardcoated polycarbonate, providing long-lasting clarity and protection against harsh environmental factors.

      Installation. Installation of the LP6 Pro is straightforward, featuring included stainless steel mounting hardware that requires minimal tools and generally no drilling for most universal mounting setups. It uses a DT06-4S Deutsch mating connector to ensure secure and reliable electrical connections.

      Warranty. This product comes with a limited lifetime warranty, providing complete purchase protection.

      Application. Fits universal vehicles; some adaptation may be required depending on mounting location and vehicle configuration.

      Baja Designs 270014

      CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

      Installation & What's in the Box

      Installation Info

      Installation Time

      (approx) 1 Hour

      Difficulty Level:

      Simple installation for anyone.

      Installation Guides

        No guide available for this part yet.

      What's in the Box

      • (1) LED Auxiliary Light Pod
      • Mounting Bracket
      • Hardware
