Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear (Universal; Some Adaptation May Be Required)
Item SHR32302
Our Price
$463.95 each
Military, Medical & First Responders
$25.52 Available in AT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Light Quantity 1 _x000D_
- Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting _x000D_
- Lighting Quantity 9 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Product Type LP9 Pro LED Light Pod _x000D_
- Secondary Amperage Rating 1.52 A _x000D_
- Secondary Brightness 2302 Lumens _x000D_
- Secondary Light Quantity 6 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology (IPT) _x000D_
- Secondary Wattage 21 W _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Universal Or Specific Universal _x000D_
- Wattage 124.2 W _x000D_
- Wiring Harness Included No _x000D_
- Amperage Rating 9 A _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Backlight Amperage Rating 0.2 A _x000D_
- Backlight Wattage 2.8 W _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 12,547 Lumens _x000D_
- Description Spot; Clear _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Exceeds MIL-STD810G Mil-Spec Testing _x000D_
- IK10 Compliant Mechanical Impact Testing _x000D_
- IP69K Waterproof Up To Nine Feet and Pressure Washable _x000D_
- Depth 3.25 Inches _x000D_
- Height 8 Inches _x000D_
- Length 8 Inches _x000D_
- Weight 6.5 Pounds _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 8 Inch and Up |
Description
Advanced LED Lighting. The Baja Designs LP9 Sport LED Auxiliary Light Pod; Driving/Combo Beam; Clear delivers a powerful total output of 12,547 lumens, providing exceptional illumination. It combines a focused spot beam with wide peripheral lighting for superior coverage on trails and roads, enhancing visibility for off-road enthusiasts and professionals.
_x000D__x000D_Construction and Appearance. Built with durability in mind, this light features a robust housing made from powder coat cast aluminum finished in black, designed to withstand harsh environments. The lens is constructed of hardcoated polycarbonate, offering impact resistance and scratch protection. Premium stainless steel mounting hardware complements the modern and rugged design.
_x000D__x000D_Installation. Installation is straightforward with included stainless steel mounting hardware and a Deutsch mating connector for secure wiring connections. Typically, no drilling is required, making this light suitable for various vehicle applications.
_x000D__x000D_Warranty. This product includes a limited lifetime warranty, ensuring protection against defects for long-term satisfaction.
_x000D__x000D_Application. Fits universal; some adaptation may be required.
Baja Designs 350003
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Installation & What's in the Box
Installation Info
What's in the Box
- (1) LP9 Sport LED Auxiliary Light Pod
