Find Light Bars & Off-Road Lighting for your Ram 1500
Baja Designs LP9 Sport LED Auxiliary Light Pod; Spot Beam; Clear (Universal; Some Adaptation May Be Required)
Item R157032
Our Price
$510.35
Military, Medical & First Responders
$25.52 Available in AT Cash Rewards.
Confirm Eligibility
Confirm Eligibility
Choose options to add to cart.
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A, Specs & Installation
Features & Specs
- _x000D_
- Lens Color Clear _x000D_
- Lens Material Hardcoated Polycarbonate _x000D_
- Lighting Quantity 9 _x000D_
- Lighting Technology LED _x000D_
- Lighting Type Forward Projecting _x000D_
- Mounting Hardware Included Yes _x000D_
- Mounting Hardware Material Stainless Steel _x000D_
- Overvoltage Protection Built-In _x000D_
- Product Type LP9 Sport LED Light Pod _x000D_
- Secondary Brightness 2302 Lumens _x000D_
- Secondary Light Quantity 6 LEDs _x000D_
- Secondary Lighting Technology LED _x000D_
- Secondary Lighting Type Integrated Peripheral Technology (IPT) _x000D_
- Secondary Wattage 21 Watts _x000D_
- Terminal Connector DT06-4S Deutsch _x000D_
- Terminal Type Mating Connector _x000D_
- Wattage 88.320 Watts _x000D_
- Amperage Rating 6.400 Amps _x000D_
- Average Rated Life 49,930 Hours _x000D_
- Beam Pattern Spot _x000D_
- Bezel Material Powder Coat Cast Aluminum _x000D_
- Brightness 9421 Lumens _x000D_
- Housing Color Black _x000D_
- Housing Material Powder Coat Cast Aluminum _x000D_
- Patent Number 5,504,603 _x000D_
- Durability Exceeds MIL-STD810G (Mil-Spec Testing) _x000D_
- Impact Resistance IK10 Compliant (Mechanical Impact Testing) _x000D_
- Water Resistance IP69K Waterproof up to 9ft and Pressure Washable _x000D_
- Depth 3.250 Inches _x000D_
- Height 8 Inches _x000D_
- Length 8 Inches _x000D_
- Weight 6.500 Pounds _x000D_
- Fits Universal; Some Adaptation May Be Required _x000D_
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Round |
| Light Size | 8 Inch and Up |
Description
High-Performance Lighting. The Baja Designs LP9 Sport LED Auxiliary Light Pod; Spot Beam; Clear delivers powerful illumination with an output of 9,421 lumens from nine forward-projecting LEDs. It also provides an additional 2,302 lumens through six integrated peripheral LEDs using Integrated Peripheral Technology, offering a broad 200-degree spread of usable light. This makes it an excellent lighting upgrade for off-road driving enthusiasts seeking both safety and style.
_x000D__x000D_Construction and Appearance. Featuring a robust powder coat cast aluminum housing and bezel in black, this light pod is designed to withstand harsh environmental conditions. Its lens is made of hardcoated polycarbonate for enhanced impact resistance. The product meets durability standards including MIL-STD810G, IK10 mechanical impact compliance, and has an IP69K waterproof rating suitable for submersion and pressure washing.
_x000D__x000D_Installation. Installation is straightforward with included stainless steel mounting hardware. Wiring harness is not included, allowing for flexibility with aftermarket options. Typically, no drilling is required, making the installation suitable for both professional installers and advanced DIY enthusiasts.
_x000D__x000D_Warranty. This product comes with a limited lifetime warranty that protects against manufacturing defects and guarantees long-term performance.
_x000D__x000D_Application. Designed to fit universal applications; some adaptation may be necessary depending on vehicle configurations.
Baja Designs 350001
